Real-time monitoring with nats-top

2 min read

Authors
banner

In this article, we will take a quick look at nats-top and see how we can use it for monitoring

What is nats-top?

nats-top is a top-like tool that provides a dynamic real-time view of a NATS server. This is a great tool for not only sys admins but developers to quickly glance at their NATS server statistics.

Installation

We can install nats-top using go

$ go install github.com/nats-io/nats-top@latest

Or using the release binaries from here

Usage

Start the NATS server with the monitoring port enabled

$ nats-server -m 8222

https://dev-to-uploads.s3.amazonaws.com/uploads/articles/kihl965iqwako2jg22ul.gif

If you're using the config, then use the http_port option

http_port: 8222

Let's see how can we use nats-top

$ nats-top --help

usage: nats-top [-s server] [-m http_port] [-ms https_port] [-n num_connections] [-d delay_secs] [-r max] [-o FILE] [-l DELIMITER] [-sort by]
                [-cert FILE] [-key FILE ][-cacert FILE] [-k] [-b]

We can configure our monitoring port, key, cert, and much more! For now, let's start nats-top with default options.

https://dev-to-uploads.s3.amazonaws.com/uploads/articles/hgwynescmamhs71pvtex.gif

Here we can see some general data such as CPU and memory usage, and input/output bandwidth.

Notice the incredible msgs/sec metric? NATS is quite performant!

Now let's use the NATS CLI and do a simple benchmark to generate some publish/subscribe events.

$ nats bench test --msgs 10000000 --pub 5 --sub 5

https://dev-to-uploads.s3.amazonaws.com/uploads/articles/heiu6zuy1jveim5ws4o2.gif

Now if we look at the nats-top we can see all the real-time info about our messages such as size, host, version, and even the programming language used by the client! Amazing right?

https://dev-to-uploads.s3.amazonaws.com/uploads/articles/lj57l4ojy325xktl9n2d.gif

Conclusion

So in this short article, we looked at how we can use nats-top for real-time monitoring. For advanced usage, make sure to explore the docs. In the next article, we will look at how you can do extensive historical monitoring of NATS clusters with the NATS Surveyor.
